ENGLISHPulse Width Modulation (PWM) Controllers
Pulse Width Modulation (PWM) Controllers-Product Selection
| Operating Voltage (Vcc) (v)
1.5-10V 30 30V 7~40V 8~35V 8~40V |
Frequency (Hz)
10KHZ 200Khz 300Khz 400Khz 500khz |
Power Consumption PD (Typ)
10mA 1W 20mA 65uA 6mA 9mA |
Operating Temperature Range (℃)
0-70°C -20~60°C -40~85°C |
Package
DIP-16 SOP-16 DIP-18 SOP-18 DIP-8 SOP- DIP-8 SOP-8 |
Alternative
KA7500 SG3524 SG3525 SG3526 TC7660 LMC7660 MC7660 ME7660 TP7660 TL494 UC2842 UC2844 UC3844 UC3844B UC2845 UC3845 UC3845B UC3842 KA3842 UC3842 UC2843 UC3843 KA3843 UC3844 KA3844 UC3845 KA3845 UC3846 KA3846 |
| Product image | Model number | Operating Voltage (Vcc) (v) | Frequency (Hz) | Power Consumption PD (Typ) | Operating Temperature Range (℃) | Package | Alternative |
 |
ICL7660 | 1.5-10V | 10KHZ | 65uA | -20~60°C | DIP-8 SOP-8 | TC7660 LMC7660 MC7660 ME7660 TP7660 |
 |
KA7500 | 7~40V | 200Khz | 6mA | -40~85°C | DIP-16 SOP-16 | KA7500 |
 |
TL494 | 7~40V | 200Khz | 9mA | 0-70°C | DIP-16 SOP-16 | TL494 |
 |
SG3524 | 8~40V | 300Khz | 10mA | 0-70°C | DIP-16 SOP-16 | SG3524 |
 |
SG3525 | 8~35V | 500khz | 20mA | 0-70°C | DIP-16 SOP-16 | SG3525 |
 |
SG3526 | 8~35V | 400Khz | 20mA | 0-70°C | DIP-18 SOP-18 | SG3526 |
 |
UC2842 | 30V | 500khz | 1W | 0-70°C | DIP-8 SOP-8 | UC2842 |
 |
UC2843 | 30V | 500khz | 1W | 0-70°C | DIP-8 SOP-8 | UC3842 UC2843 |
 |
UC2844 | 30V | 500khz | 1W | 0-70°C | DIP-8 SOP-8 | UC2844 UC3844 UC3844B |
 |
UC2845 | 30 | 500khz | 1W | 0-70°C | DIP-8 SOP-8 | UC2845 UC3845 UC3845B |
 |
UC3842 | 30V | 500khz | 1W | 0-70°C | DIP-8 SOP-8 | UC3842 KA3842 |
 |
UC3843 | 30V | 500khz | 1W | 0-70°C | DIP-8 SOP- | UC3843 KA3843 |
 |
UC3844 | 30V | 500khz | 1W | 0-70°C | DIP-8 SOP-8 | UC3844 KA3844 |
 |
UC3845 | 30V | 500khz | 1W | 0-70°C | DIP-8 SOP-8 | UC3845 KA3845 |
 |
UC3846 | 30V | 500khz | 1W | 0-70°C | DIP-16 SOP-16 | UC3846 KA3846 |
